CZP series liquid filling machine

This machine can finish glass or plastic bottle filling, lidding and capping.

CZP series liquid filling machine

CZP series liquid filling machine

Our bottling machines / beverage machines are widely used in the manufacture of disinfection syrup,disinfectant and disinfectant alcohol, water, fruit juice, soft drinks, milk, functional drinks, carbonated drinks, etc. Please contact us for more information.

Capacity 5000~7000 bottles/hour
Filling range 50~350ml
Filling head number 8~12 heads
Filling accuracy 0~2%
Lock number Double head
Locking method Capping, ordinary capping, pilfer-proof capping etc.
Voltage 380V 50Hz three-phase four wire system
Power 2Kw
Dimensions 3400*950*1650mm
czp liquid filling machine
czp liquid filling machine1
czp liquid filling machine2
czp liquid filling machine3

LTXG series liquid filling machine

This machine can finish glass or plastic bottle filling, lidding and capping.

LTXG-2 Liquid Filling Sealing Machine

LTXG-2 liquid filling machine

It suits for foodstuff, pharmacy, daily chemicals, pesticide and chemical industry.
It is suitable for glass bottle,PET bottle and all kinds of plastic bottle.It is especially for carbonated drinks with syrupinside.

Filling speed 2 head
Range 100ml-2000ml
Speed 100-1500bottles/h
Measurement precision ±1%
Working voltage 220V
Working air pressure 0.12m2/h
Net weight 200kg
Contour Sizes 1000x1000x1900mm

LTXG-2 Liquid Filling Sealing Machine In feed valve
LTXG-2 Liquid Filling Sealing Machine Motor driver
LTXG-2 Liquid Filling Sealing Machine Inverter
LTXG-2Eco Liquid Filling Machine (1)

LTXG-2ECO liquid filling machine

Filling liquid: water, beverage, sauce, cream, paste, oil, etc.

Applicable Bottle Shape: Round, Flat, Oval, Irregular, Square, Jar, Can, etc.

Bottle Material: HDPE, Aluminum, Plastic, Glass, etc.

LTXG-2Eco Liquid Filling Machine (2)
LTXG-2 Liquid Filling Sealing Machine In feed valve
LTXG-2 Liquid Filling Sealing Machine Motor driver
LTXG-2 Liquid Filling Sealing Machine Inverter
Model Name LTXG-2Eco LTXG-4Eco LTXG-8Eco LTXG-12Eco LTXG-16Eco
Filling Nozzle 2 4 8 12 16
Production Capacity 20 30 50 60 70
Applicable Filling Material Cream, Ointment, Water, Juice, Water-Like Liquid, Oil, Paste, etc.
***Note: Different Material May requires different filling Pump, please tell before you order the machine
Filling Accuracy 200ml: +/-1%, 200-5000ml: +/-0.5%
Filling Range 50-5000ml
Power Supply (without heating) 1Kw 2kw 2.5kw 3kw 5kw
Power Supply 380v 50hz Three phase
Air Pressure 0.6Mpa
Applicable Bottle Shape Round, Flat, Oval, Irregular, Square, Jar, Can, etc.
Bottle Material HDPE, Aluminum, Plastic, Glass, etc.
LTXG41 Automatic Oral Liquid Filling And Capping Machine

LTXG-4/1 liquid filling machine

LTXG4/1 Automatic Filling and Capping machine for the application of light liquid filling and capping for plastic or glass bottles.

LTXG-2Eco Liquid Filling Machine (2)
LTXG41 Automatic Oral Liquid Filling And Capping Machine2
LTXG41 Automatic Oral Liquid Filling And Capping Machine1
LTXG41 Automatic Oral Liquid Filling And Capping Machine (3)
Kind of bottle Various kinds of plastic/glass bottle
Bottle size* Min. Ø 20mm Max. Ø80mm
Kind of cap Alternative Screw on cap, alum. ROPP cap
Cap size* Ø 20~ Ø45mm
Filing nozzles 4heads
Speed 30~50bpm
Alternative Filling volume* 15~60ml, 30~125ml, 50~250ml, 200~500ml
Filling accuracy ±1%
Power* 220V 50/60Hz 1.2kw
Compress air require 10L/min, 4~6bar
Machine size mm Length 2500, width 1000, height 1600
Machine weight: 800kgs

RotaFill-Series Automatic Bottle Liquid Filling Machine

This unit is a combined multi-functional unit that integrates washing, filling and capping.

RotaFill-Series Automatic Bottle Liquid Filling Machine

RotaFill-Series Liquid Filling Machine

They can suitable for different sizes bottles in the designing scale.
It is suitable for glass bottle,PET bottle and all kinds of plastic bottle.It is especially for carbonated drinks with syrupinside.

Capacity 2500BPH (500ml)
Bottle Height 150~310mm
Bottle Diameter 50~96mm(diameter)
Bottle Type PET bottle
Cap HDPE Cap
Washing Head 8
Washing Capacity 1000kgs/hour
Washing Pressure 0.2-0.4Mpa
Filling Heads 8
Capping Heads 3
Rated Voltage 220V/380V,50/60HZ, 3 phase
Main Motor Power 1.5kw
Total Motor Power 3kw
Overall dimension 2000*1800*2100mm
Weight 1800Kg
RotaFill-Series Automatic Bottle Liquid Filling Machine5
RotaFill-Series Automatic Bottle Liquid Filling Machine4
RotaFill-Series Automatic Bottle Liquid Filling Machine2
RotaFill-Series Automatic Bottle Liquid Filling Machine1

LTHG-Series Piston-type automatic filling machine

This unit is a combined multi-functional unit that integrates washing, filling and capping.

LTHG-6 Piston-type automatic filling machine

LTHG-6 Piston-type automatic filling machine

It is widely used for filling various liquids, viscous bodies and pastes, and can be used for filling semi-fluids, pastes, sauces, etc. containing particles.

LTXG-2Eco Liquid Filling Machine (2)
Model LTHG-6
Filling capacity 100-1000ml
Filling speed 1500 bottles/hour (depending on bottle size and filling volume)
Filling accuracy <±1%
power supply 220V 50HZ
power 3KW
Air pressure 0.4-0.6MPa
size 2000*900*1900mm
weight 400KG

Automatic Rotary filling machine

Compact conformation, good shape, cozy operation, excellent automaticity and poor labor intensity.

Automatic Rotary filling machine

Automatic Rotary filling machine

They can suitable for different sizes bottles in the designing scale.
It is suitable for glass bottle,PET bottle and all kinds of plastic bottle.It is especially for carbonated drinks with syrupinside.

Capacity 36000BPH    (500ml)
Bottle Height 120~310mm
Bottle Diameter ф50~ф96mm
Mouth Diameter 26mm~40mm
Bottle Type PET bottle
Cap HDPE Cap
Washing Head 80pcs
Washing Time >2second
Filling Heads 80
Filling Temperature 85-90℃
Filling Pressure 0.2~0.4Mpa
Filling Valve    Flow 120~150ml/s
Filling Pipe SUS304, High    temperature affordable
Capping Head 18
Capping Strength 0.6~2.8Nm(adjustable)
Main Power 15 KW
Air Consumption 1m 3/min(0.6MPa)
Sterilized Water Consumption 1.2m3/h(0.2-0.25Mpa)

ALG-Series Ampoule Filling Sealing Machine

The machine is a new generation of the ampoule filling and sealing machine for several size.

ALG Series Ampoule Filling and Sealing Machine

Alg-6 Ampoule Filling Sealing Machine

The machine is a new generation of the ampoule filling and sealing machine for several size.

Filling volume 1-2ml 5-10ml 20ml
Capacity 10000pcs/hour 5000-10000 pcs/hour
Power 0.75 kw
Gas consumption 1-2m2/h
Pressure 0.08-0.1MPa
Combustion-supporting Consumption Oxygen 0.7-1m2/h 0.1MPa
Overall dimension 1700*1030*1500mm
Weight 800kgs
ALG Series Ampoule Filling and Sealing Machine4
ALG Series Ampoule Filling and Sealing Machine4
ALG Series Ampoule Filling and Sealing Machine4

SupLab-Series Automatic suppository filling production line

Suitable for the production of special shape such as bullet head, torpedo shape and duck bill.

suplab2 suppository filling machine

SupLab-Series Automatic suppository filling production line

— Suitable for the production of special shape such as bullet head, torpedo shape and duck bill.
— Adapt material: synthetic fatty acid glycerol, glycerin gelatin, polyethylene glycol etc.

Model SupLab-1 SupLab-3 SupLab-7 SupLab-10
Output 1000-1500 pcs/h 4500-5000 pcs/h 10000 pcs/h 15000 pcs/h
Single dosage 0.5—5g 0.5—5g 0.5—5g 0.5—5g
Dosage allowed <±2% <±2% <±2% <±2%
Packaging Film PVC\PE PVC\PE PVC\PE PVC\PE
Stirring tank capacity 20L 30L 70L 70L
Air pressure ≥0.6Mpa ≥0.7Mpa ≥0.7Mpa ≥0.7Mpa
Air consumption 1.2m³ 1.5m³ 1.5m³ 1.5m³
Water consumption 50kg(recycling) 50kg(recycling) 50kg (recycling) 50kg (recycling)
Working voltage 3 phase 380V 3 phase 380V 3 phase 380V 3 phase 380V
Total power 4KW 5KW 7.5KW 9.5KW
Machine Weight 500KG 1000KG 2000KG 2500KG
Overall dimensions 2300*1200*1800mm 3587*1388*1828mm 5302*2120*1809mm 5965*2120*2,150mm
suplab2 suppository filling machine3

Servo high precision filling system

suplab2 suppository filling machine4

The insertion type linear perfusion mechanism

suplab2 suppository filling machine5

Production capacity

suplab2 suppository filling machine2

exclusive circulation of water cooling system

ABOUT LTPM CHINA

LTPM CHINA1

A Pharma Machinery Division, For A Better Life.

“Our company is recognized as a major pharmaceutical equipment manufacturer and a distributor of packaging materials and pharmaceutical chemicals.
Our company is founded in Rui’an, China, with 18 years’ (Opened on 1996 year) experience in pharmaceutical industry.
This allows us to expand our business in a well-planned manner.
We now offer a comprehensive whole production line of quality pharmaceutical machines,packing materials and APIs at competitive prices.”

Professional Technical Support and Excellent Service.

“Based on our experienced engineering team, we produce top quality machines, packing materials and APIs and also help customers select the best quality suppliers.
Our company is a technology-driven company and focuses on producing high quality machinery. We employ 15 engineers on machinery design and technology improvement.
Each engineer has at least ten years’ machining and packaging area experience. We are your extra technical consultant center.”

LTPM CHINA Quality Control1

Strict Quality Control and Multiple Certificates.

“Our company owns a quality control department to verify each product at different phases, from the procurement of parts to finished products. In order to offer clients the best quality products, we manufacture products in accordance with international standards, such as FDA, GMP and cGMP.
We are your best pharmaceutical production solution!”

F.A.Q.

A:The alcohol content of the material is ≥5%, and the machine should be equipped with an explosion-proof device.

A:The explosion-proof motor has the function of explosion-proof and high sealing performance.

A:No, because it doesn’t have a motor, just a solenoid valve.

A:It is necessary to know whether the aluminum foil used by the customer for sealing is in a roll or a sheet, which is directly related to the choice of the machine.

A:Determined according to the actual material situation. Usually peristaltic pumps are not suitable for viscous materials. The ceramic pump is suitable for filling materials below 20ml. Stainless steel piston pumps are suitable for viscous materials.

A:The pump for filling hand sanitizer can be used for filling shampoo and shampoo oil.

A:All pumps can be filled from the bottom.

A:Yes, the peristaltic pump has high precision and is suitable for materials with high fluidity.

Materials with high viscosity can use ceramic pumps and stainless steel pumps, which are not easy to clean, but are also suitable.

A:The same machine can be used, but the capping head needs to be replaced.

A:The cap elevator can be used for different sizes of caps without changing the mold.

A:The linear rotating capping machine is easier to use than the linear screw capping machine. The linear rotating capping machine has a higher capping pass rate and the linear screw capping machine is faster.

A:Yes, the press capping machine is a machine for aluminum caps only.

A:The rotating capping machine is usually used for screw caps, the screw capping machine is used for screw caps without anti-theft ring, and the press capping machine is used for metal caps.

The screw capping machine simply twists the cap.

The press capping machine is to force the cap on the bottle mouth. The press capping machine is generally used on plastic bottles, such as mineral water, lubricating oil, and edible oil.

The screw capping machine is suitable for screw caps, no need to change the mold, but the torque adjustment range is limited. The capping machine can easily damage the surface of the cap.

The rotating capping machine is generally used for iron caps, generally used in sauces, canned fruits and other places.

The rotating capping machine needs to replace the mold, but the torque is easy to adjust, and it is not easy to damage the cover surface.

A:Comply with FDA standard: one vial filling and stopper machine, one vial capping machine.

Not FDA compliant: vial filling, stoppering and capping all-in-one, so all three functions are on the same machine.

A:The vial sterilization channel is used for testing, and the vial sample is not required.

A:The linear filling machine is convenient to replace accessories, easy to disassemble, and more in line with GMP requirements, but it has greater requirements on the site.

The bottled washing filling capping producing line is more suitable for high-speed filling of beverages, and the cost of replacing the mold is higher.

A:The organic glass cover of the bottle washer is pneumatically driven and controlled by a touch screen.

A:1. In case of overturning the bottle, etc., it can be handled by hand;

  1. Under normal circumstances, if pure water is passed in, it does not have to reach 60 degrees, and room temperature is also fine.

A:The filling mineral water plastic bottle is washed with water, and there is water in it that can be directly filled.

Glass bottles are suitable for both air washing and water washing.

Plastic bottles for other purposes are best washed with air, because if the bottle is washed with water, it needs to be dried.

A:The filling needles of stainless steel, silica gel and PTFE can be disassembled for sterilization and cleaning.

A:The level of the workshop should reach C level or above.

A:Water treatment, dosing, weighing, filling and packaging.

A:The roll film liquid filling machine can be sterilized with a water bath, but not with steam. Use a rapid-cooling sterilizer or keep the pressure for cooling.

A:Usually the semi-automatic liquid filling machine is pneumatic, and the filling amount is controlled by the formation of the cylinder.

The automatic liquid filling machine controls the filling amount depending on what pump is used for filling. Different pumps have different adjustment and control methods, but the automatic liquid filling machine can be adjusted and controlled on the touch screen.

A:Rotary filling machine or reciprocating filling machine.

A:The filling volume is inaccurate and the pump body is worn.

A:When the liquid splashes out during the filling process, adjust the filling speed. When there is liquid leakage during the filling process, pneumatic blow-off, pneumatic partition, and leakage devices can be used.

A:Yes, square and round bottles can be run on the same liquid filler machine.

A:The 100-level FFU laminar flow hood is an air purification equipment that can provide a local high clean environment. The product is compact in structure, easy to use, and can be hung or supported on the ground.

The 100-level layer FFU laminar flow hood can be used alone, or can be used in multiple connections to form a strip-shaped clean area. The FFU laminar flow hood is a uniform flow layer, which is formed after passing the air through a high-efficiency filter at a certain wind speed, so that the clean air flows in a vertical unidirectional flow, thereby ensuring the cleanliness of the working area to meet the process requirements.

A:The motor of the filling machine and the conveyor belt are connected with a belt: low noise, easy to wear

The motor of the filling machine and the conveyor belt are connected with a chain: there is noise.

A:It is used at the butt joint of the conveyor belt to ensure smooth bottle feeding without accumulating and pouring bottles.

A:Transparent bottles can be verified by liquid level detection, but the cost is high and the accuracy is average. It is usually done with a weighing machine.

A:When adding the audit trail function, it is necessary to replace the touch screen and add programs. All machines can have an audit trail.

A:No, there are differences between 316 materials at home and abroad. The ductility and toughness of 316 materials are not as good as 304 materials.
